SMM3000X Series Source Measure Units

  • 6½ Display digits (2,100,000 count)
  • Maximum acquisition rate of 100,000 points/s
  • Minimum programming and measuring resolution of 10fA/100nV
  • 210V/3.03A(DC)/10.5A(pulsed) maximum output
  • Support DC, pulse, scanning and list output, with a minimum pulse width of 50μs
  • 5-inch touch screen, supporting graphic and digital views.
Categories: ,
Contact Sales Spec Sheet

Description

Product Overview

SMM3000X series is an accurate source/measuring unit (SMU) instrument, which can output and measure voltage and current at the same time. It integrates the functions of current source, voltage source, voltmeter and ammeter, and is especially suitable for semiconductor characteristic analysis, nano-scale devices and materials, organic semiconductors and other testing applications.

Watch Product Video

Key Features

  • Five-inch, high resolution capacitive touchscreen GUI
  • Source and measurement resolution down to 10 fA and 100 nV
  • The maximum display digits: 6½(21,000,00 count)
  • The maximum sampling rate is 100ksps, the sampling interval is 0.0005 PLC, and the maximum setting is 100 PLC.
  • Minimum trigger interval 10 μs.
  • Up to 100k points of internal storage space, supporting timestamps.
  • Four-quadrant precision power supply with single/dual-channel output and measurement
  • Voltage (±210 V) and current (± 3 A DC and ±10.5 A pulsed) sourcing capability
  • Five basic functions: voltage/current sourcing, voltage/current/resistance measurement
  • The minimum programmable pulse width is 50 μs.
