Contact Sales Description
●Compact & lightweight
(168 channels in 290 W × 100 H × 210D mm, approx. 9 kg)
●High impact resistant: 100 G
●Synchronous measuring channels up to 1056
(Up to 999 channels when using DIS-70A)
●Outputs ignition current based on the pre-set delay time. (DIA-708A)
●Records the CAN data. (DIC-706A)
Contents
■Master Module
DIS-7000A
■Slave Modules
DIS-724A-T/L (Signal Conditioner Module)
DIA-708A (Airbag Timer Module)
DIC-706A (CAN Measurement Module)
■Control Software
DIS-70A
Block diagrams
