KFWB series
Waterproof Foil Strain Gages

KFWB Series
Waterproof Foil Strain Gages

Description

The surface of the KFWB series foil strain gage is covered with a special waterproof resin.
The waterproof structure enables these gages to serve for outdoor or underwater measurement merely by being bonded to measuring objects.
(The insulation resistance shows virtually no deterioration even after 100 hours of use under an underwater pressure of approximately 10 MPa.)
In addition, the covering resin is flexible enough to enable easy bonding to curved surfaces.

Relative images

KFWB

Contents

When ordering, suffix the lead-wire cable code to the model number with a space in between.

E.g.
KFWB-5-120-C1-11 with a vinyl-coated flat 2-wire cable 2 m long
→ KFWB-5-120-C1-11 L2M2R

KFWB-5-120-D17-11 with a vinyl-coated flat 3-wire cable 5 m long
→ KFWB-5-120-D17-11 L5M3S

KFWB Series
Waterproof Foil Strain Gages

KFWB 120Ω Uniaxial

KFWB

KFWB 350Ω Uniaxial

KFWB

KFWB 120Ω Biaxial, 0°/90°stacked rosette

KFWB

KFWB 350Ω Biaxial, 0°/90°stacked rosette

KFWB

KFWB 120Ω Triaxial, 0°/90°/45°stacked rosette

KFWB

KFWB 350Ω Triaxial, 0°/90°/45°stacked rosette

KFWB

Remarks

Notes on pre-attached lead-wire cables
∙ Standard color of the 2-wire cable pre-attached to uniaxial gages is red (R).
If desired, allows a white, green, yellow or black cable to be pre-attached.
∙ Standard 3-wire cable pre-attached to uniaxial gages has red stripes (R).
If desired, allows the red stripes to be changed to blue or yellow stripes.
∙ In the case of a biaxial gage and triaxial gage, 2-wire cables are color-coded with red, white and green stripes for 0°, 90° and 45°, respectively and 3-wire cables, with red, yellow and blue stripes for 0°, 90° and 45°, respectively.
The letter code is S in common.
