Special Components for High Frame Rates
The measurement system enables the creation and storage of thermographic sequences with very high frame rates ranging up to some kHz. The thermal behaviour of high-speed processes can be monitored and analysed. An example is the optimisation of airbags as the heat distribution during the explosion can well be analysed.
High-speed thermography with frame rates of more than 100 kHz are based on special detectors and acquisition units. Especially their ability to acquire and read out data in parallel provides thermographic measurements precisely in a millisecond range. Those detectors are so-called snapshot detectors which are integrated by InfraTec in their ImageIR® infrared camera series.
10 GigE Interface for a Strong Increase in Output
The new 1 Gigabit Ethernet interface of the high-end camera series ImageIR® opens this extremely fast transmission standard with a NIC specially developed by InfraTec. This works with optical or electrical transceiver modules that are easy to change and are called SFP+. For all models of the ImageIR® 8300 hp with their (640 × 480) IR pixel detectors this leads to a transfer rate in the full frame mode up to 355 Hz. Users can store large quantities of data to a computer easily and reliably.
Different 10 GigE fiber SFP+ transceivers allow transmission ranges of up to ten kilometers with the same low sensitivity to electromagnetic interference. A corresponding standard SFP ensures backward compatibility with the conventional GigE interface. This combination allows the ease of use of the cameras with the new 10 Gigabit Ethernet interface in existing systems – though at a reduced transmission rate.
Detect More on Smaller Objects
A well-balanced range of interchangeable precise radiometric infrared lenses covers the fields of telephoto lenses, standard lenses, wide-angle lenses as well as macroscope and microscope lenses. This again, allows the adoption of the field of view for nearly each measuring situation. All changeable state-of-the-art standard optics of ImageIR® can be equipped with a motor focus unit. It allows for precise, remotely controlled and fast motorised focusing and is part of a reliable autofocus function. Due to a diversity of microscope lenses detailed images of electrical assemblies and components can be taken even from larger measuring distances with a pixel size of up to 5 µm.
